The Platinum Sport 1000

The Platinum Sport 1000

High Performance Fuel and Ignition ECU
With 8 channels capable of controlling injection and ignition duites, the Platinum Sport 1000 can support most modern engines (including 2 rotor engines) with multi-coil or conventional distributor ignition systems as well as aftermarket CDI systems.
It is capable of controlling sequential injection on engines up to 4 cylinders, or semi-sequential up to 8 cylinders, combined with direct fire ignition for engines up to 4 cylinders or wasted spark ignition on engines up to 8 cylinders.

Features:

• - 8 additional user-definable auxillary inputs
• - Up to 9 additional user-definable auxillary outputs (Depending on configuration)

Features and user-definable outputs available as standard include, but are not limited to:

• - Fully user-definable 32 x 32 mapping ( Up to 1024 points)
• - Wideband "Auto tuning" using user definable target AFR table
• - Narrow and Wideband closed loop O2 control
• - Staged injection control for multiple injectors per cylinder (inc rotary)
• - 3D mapped rotary engine ignition split
• - Soft and hard cut rev limiter
• - EGT fuel correction
• - Tuning via TPS with manifold pressure correction
• - Dual map switching for fuel/ign/boost
• - Anti-lag (Rally and Launch style)
• - Rotational idle
• - Launch Control
• - VTEC cam timing control
• - VANOS cam control (intake cam only)
• - True variable cam control supporting late model Toyota's, WRX's and EVO's
• - Dual intake runner control
• - Onboard 2.5 BAR MAP sensor (or use with external MAP up to 10 BAR)
• - Custom sensor calibration (Use your own sensors for temps or fuel/oil pressure etc)
• - Open or closed loop boost control ( Road speed, RPM or gear based mapping)
• - Closed loop idle control (Stepper motor and BAC type)
• - Extra injector control
• - Thermo-fan control ( Duty cycle or on/off )
• - Intercooler fan/spray
• - Alternator control (Mazda)
• - Engine control relay function
• - Nitrous switching with fuel / ignition correction
• - Staged shift lights
• - Aux fuel pump control
• - Tacho output (5v,8v,12v)
• - Turbo timer
• - Torque converter lock up
• - Air con request idle up
• - Windows 2000, XP, Vista compatible software
• - "In the field" updatable Firmware provides all the new features as soon as they are available
• - Onboard and laptop data logging with Data Viewer software
• - USB communication with laptop/PC
• - CAN Bus port for direct plug in communication with Racepak and Aim Dash system.

Typical Applications:

- Control of fuel injection on modified engines
- Conversion from carburetion to fuel injection
- Race and rally applications of all description
- Design and development purposes
- Educational use by universities and technical colleges
- Original equipment in cars and motorcycle

The Platinum Sport 1000 (ECU only kit) includes:

ECU Programmable Computer, USB Programming Cable,Instruction Manual (In Software),
Programming software

Platinum Sprint 500

Engine Suitability:

• 1 to 8 Cylinder engines
• Normally Aspirated or forced induction
• Load sensing by throttle position or manifold pressure (MAP)
• Sequential, semi-sequential, batch or multi-point injection patterns
• Distributor ignition systems or multi-coil systems

Trigger Types:

• Hall Effect
• Optical
• Inductive Magnetic Reluctor

Trigger Patterns:

• Single Pulse per cylinder
• Multi-tooth
• Bosch Motronic
• Ford
• GM
• Honda
• Mazda
• Mitsubishi
• Nissan Optical
• Subaru
• Toyota
• Volkswagen

Features:

• Windows 2000, XP, Vista compatible software
• Real time programming, instant hesitation free adjustment while engine is running
• Fully user definable 16 x 16 mapping
• Tuning via Volumetric Efficiency (VE), Injection time
• Selectable onboard internal MAP sensor rated to 150kPa (up to 1.5 Bar or 22psi boost)
• USB and CAN Communication Port
• Custom sensor calibaration allows for most factory sensors to be used
• 2 x User programmable outputs

ECU Fixed Outputs:

• 4 x Fuel Injector outputs (for high impedance injectors only
(ie: above 8Ω)
• 4 x Ignition outputs
• Tacho
• Thermo Fan
• Fuel Pump

ECU Programmable Outputs:

• 2 x Programmable Outputs

ECU Inputs:

• Air Temperature
• Aux Rev Limiter
• Coolant Temperature
• Manifold Absoloute Pressure
• Roadspeed
• Throttle Position
• O2 Sensor (Narrowband or Wideband)

Functions:

• CAN Communication
• O2 Control
• Over Boost
• Gear Setup
• Decel Cut
• Transient Throttle Enhance
• Rev Limiter

Correction Tables: Fuel / Ignition:

• Air Temp Correction
• Barometric Correction
• Coolant Temperature Correction
• Injector Dead Time
• Map Correction
• Post Start
• Prime Pulse
• Wide Open Throttle
• Zero Throttle

Miscellaneous:

• Tune can be password protected in software
• Small and compact design
• Rugged anodized aluminum casing

Power Requirements:

Source: 8.6 to 16.5 Volts DC
Consumption: 360mA @ 12Volts DC

Physical Dimensions:

ECU Dimensions Length: 134mm (154mm with MAP nipple)
Width: 64mm Height: 28mm Weight: 195g (0.43 lb)

The Platinum Sprint 500 Kit includes:

Platinum Sprint 500 ECU,Platinum Sprint 500 Flying Loom, USB Cable, Programming Software CD,
Quick Start Guide, Instruction Manual (on CD), Haltech Sticker
